2.4 Programmer Operating Modes
The ISPnano programmer can be controlled in various different ways as detailed in the table below:
# Programmer Mode
Control
Software
U/ Functional description
S
Refer
to
section
1 Development Mode
EQTools -
EDS
S In this mode, the programmer is controlled
by EQTools - Equinox Development Suite
2.5
(EDS). EDS allows you to read/write the
target device FLASH / EEPROM / FUSE /
LOCK bits interactively under PC control
without uploading a ‘Programming Project’
to the programmer.
2 Standalone -
Keypad Mode
None
S In this mode, the programmer is not
connected to a PC and can program a
2.6
single ‘Programming Project’ into the
Target Device when the <START> key is
pressed. (A valid project must have been
previously uploaded to the programmer
using EQTools – Upload Wizard.)
3 Standalone -
Any Terminal S This protocol can be used to control an
2.7
ASCII Text
Communications
Control
Emulation
Software
Equinox programmer from a Remote
Application or Remote System using a
simple set of ASCII serial commands. This
protocol is ideal for controlling Equinox
programmers from any Remote System
which features an RS-232 serial port and
which can operate at a fixed baud rate of
38,400.
4 Standalone -
4-Wire TTL Control
None
S The programmer can be controlled using a
4-wire TTL signalling protocol as shown in
2.8
the diagram below. This control method is
ideal for interfacing the programmer In-
Circuit Testers (ICT’s) or other production
equipment which does not have an RS-232
port.
5 Target System
auto-detect mode
None
S The programmer is capable of automatically 2.9
detecting when a Target System is
connected to / disconnected from the
programmer. This can be used to trigger the
execution of a Programming Project in
Standalone Mode.
ISPnano Series Programmer - User Manual – V1.11 – 12 May 2011
th
29
